RCBO Schrack 1 module 30ma A C16A
€18.66
AI667516
- 6kA short circuit capacity
- Type C tripping curve
- Fault tripping 30mA
- Type: AC
- Available with neutral leads
- Suitable for single pole busbar
- Incoming terminal capacity 35mm2
- Outgoing terminal capacity 25mm2
- Disconnect both L and N
- Tested to EN61009-1
| EAN-Code | 9004840872675 |
|---|---|
| Net width | 18,00mm |
| Net height | 94,00mm |
| Netto depth | 73,30mm |
| Net weight | 0,18kg |
| Power loss | 4,50W |
| Min. ambient temperature | -25°C |
| Max. ambient temperature | 40°C |
| Tripping characteristics | C |
| Amperage | 16A |
| Poles | 1+N |
| Type | undelayed |
| Product category | A |
| Series | AMPARO |
| Rated breaking capacity | 6kA |
