Push in Cable connector
PC253 Connector
Push-In Wire Connectors, Standard PA – PC25 series
• Flame retardant (UL 94V-2) shell of polyamide 66, Τ110 (IEC)
• Maximum operation voltage:
• MAX 600V for domestic cabling/wiring
• MAX 1000V for lighting or panel installations, etc.
• Color separation for facilitating the use
• Small size (suitable for limited space)
• IEC/EN 60998, UL 486C Listed
• Maximum operation voltage:
• MAX 600V for domestic cabling/wiring
• MAX 1000V for lighting or panel installations, etc.
• Color separation for facilitating the use
• Small size (suitable for limited space)
• IEC/EN 60998, UL 486C Listed
Electrical Characteristics
• Current: 24Α
• Voltage: 450V
• Operation Temperature: +110°C
• Wire range: 1~2.5mm², Sol
• Current: 24Α
• Voltage: 450V
• Operation Temperature: +110°C
• Wire range: 1~2.5mm², Sol
