Insulation Tester Digital DT5520

€195.00

DT5520

Insulation Tester Digiatl CEM
Specifications
Max Resolution
Basic accuracy
Voltage AC750V 1V±1.2%rdg ±10dgts
Voltage DC 1000V 1V ±0.8%rdg ±3dgts
Resistance:200Ω, 2000Ω 0.1Ω, 1Ω
±1%rdg ±2dgts
Insulation Resistance
200MΩ,100kΩ~1MΩ 10kΩ
±3.5%rdg ±5dgts ±3.5%rdg ±5dgts
Test Voltage
250V-200MΩ/500V-200MΩ/1000V-2000MΩ, (500V-20MΩ only 5520)
Continuity Test
Active Sound Level: ≤40Ω, Test current ≤200mA
Operating Temp0ºC~40ºC (<80%R.H.)
Storage Temp-10ºC~60ºC (<70%R.H.)
Power Source: AA Battery x 6
