Clamp meter Watt/kw/kvar/kva DT3343T
€156.00
DT3343T
Watt/Kvar/Kva Tru RMS Clamp meter:
AC voltage measurements up to 750V and AC current up to 1000A.
Active power measurement 0.60-750kW, apparent power 0.60-750kVA,
Idle power 0.60-750kVAr
Power factor 0.3-1,
Frequency 20-200 Hz,
Phase angle 0-90 degrees
Consumption up to 1-9999 kWh.
Memory data of 99 positions.
Non-contact voltage indicator.
Large LCD backlit display. Max / Min indications.
Data Hold,Auto Power off functions.
The package includes a 9V battery, test terminals, USB cable, software CD and carrying case.
| Specifications | ||
| Function | Range | Basic Accuracy |
| AC Voltage | 15V/100V/300V/750V | ±(1.2%+5) |
| AC Current | 40A/100A/400A/1000A | ±(2%+5) |
| True Power | 0.60kW—750kW | ±(3%+5) |
| Apparent Power | 0.60kVA—750kVA | ±(3%+5) |
| Reactive Power | 0.60kVAr—750kVAr | ±(4%+20)of 15V/1000A else±(4%+5) |
| Power Factor | 0.3-1 | ±(2%+20) |
| Phase Angle | 0°-90° | ±1° |
| Frequency | 20Hz-200Hz | ±(0.5%+5) |
| Energy | 1-9999kWh | ±(3%+2) |
